características
MODELO | LG 500 | LG 800 | LG 1000 | LG 1370 | LG 1570 |
---|---|---|---|---|---|
Mesa (x, y) [mm] | 620 x 420 | 950 x 510 | 1150 x 510 | 1400 x 650 | 1600 x 650 |
Recorrido (x, y) [mm] | 520 x 420 | 800 x 510 | 1000 x 510 | 1300 x 700 | 1500 x 700 |
Altura máxima (z) [mm] | 550 | 730 | 730 | 800 ( 1000 OPC ) | 800 ( 1000 OPC ) |
Avance de mecanizado [m/min] | 12 | 12 | 12 | 15 | 15 |
Cono | 40 | 40 | 40 | 40 | 40 |
Almacen de herramientas | 24 | 16 ( 24,30 OPC ) | 16 ( 24,30 OPC ) | 16 ( 24,30,40 OPC ) | 16 ( 24,30,40 OPC ) |
Potencia [HP] | 7,5 ( 10 OPC ) | 10 ( 15 OPC ) | 10 ( 15 OPC ) | 15 ( 20 OPC ) | 15 ( 20 OPC ) |
Peso [kg] | 3300 | 4300 | 4530 | 8300 | 9000 |
Debido a las mejoras que puedan sufrir en un futuro, el fabricante se reserva el derecho de modificar las características técnicas sin previo aviso.
