Centro de Mecanizado Vertical Linea MVP

  • Alta presición
  • Alta velocidad de rotación y traslación (sobre guías lineales)









Foto no contractual

Hartford

VIDEO

características



MODELO MVP 8 MVP 10 MVP 13 MVP 15 MVP 16
Mesa (x, y) [mm] 1000 x 560  1150 x 560  1270 x 600  1400 x 700  1750 x 820
Recorrido (x, y) [mm] 860 x 530  1050 x 530  1100 x 600  1300 x 700  1600 x 820
Altura máxima  (z) [mm] 715  715  730  770  820 (1020 OPC)
Avance de mecanizado [m/min] 20  20  20  20  20
Cono 40 40 40 40 40 (50 OPC)
Almacen de herramientas 16 ( 24,30 OPC ) 16 ( 24,30 OPC ) 16 ( 24,30,40  OPC ) 24 ( 30,40  OPC ) 16 ( 24,30,40  OPC )
Potencia [HP] 10 ( 15 OPC ) 10 ( 15 OPC ) 10 ( 15,20,25 OPC ) 15 ( 20,25 OPC ) 20 ( 25 OPC )
Peso [kg] 6500  6700  6300  9000  11500





Debido a las mejoras que puedan sufrir en un futuro, el fabricante se reserva el derecho de modificar las características técnicas sin previo aviso.
